/ / 5 kVA - 10 kVA


KOEL Chhota Chilli Brand

KOEL Chhota Chilli is the Genset brand of Kirloskar Oil Engines Ltd (KOEL), the flagship company of the century-old Kirloskar Group. KOEL also manufactures KOEL Green which is India's largest selling and most trusted Genset brand for over a decade. Providing backup power solutions from 5 to 5200 kVA for diverse market sectors, KOEL Green and KOEL Chhota Chilli have over 1 million Gensets in service across the globe.

Research and Engineering

KOEL Chhota Chilli Gensets are designed and developed indigenously, using modern design & simulation technologies. KOEL's R&D team combines decades of application knowledge, global technology trends and emerging user expectations to develop best-in-class products for the target markets. The products are launched aer extensive validation in world-class facilities.

State-of-the-art Manufacturing

KOEL Chhota Chilli Gensets are manufactured at the state-of-the-art manufacturing facilities of KOEL and authorized GOEMs across India. Common design, modern infrastructure, trained manpower, stringent process controls and standardized material quality ensure that every KCC Genset complies with the standards and meets KOEL's stringent quality norms

Sales Network

A well-trained network of authorized KOEL Chhota Chilli Dealers and GOEM Sales teams is spread across India to serve your requirements. KOEL offices at key locations provide further techno- commercial back-up. KCC Sales teams are equipped to carry-out load study, Genset sizing and techno- commercial support. Installation and commissioning activities are also undertaken in line with KOEL's stringent guidelines

Service Network

As Gensets cannot be driven to a Service Station, service has to come to your door-step. KOEL Chhota Chilli Gensets are supported by over 5000 trained engineers and over 450 well-equipped service outlets throughout India. Standard and custom-made maintenance packages offer a total –peace-of- mind ownership experience. Service response me and quality is centrally monitored for cross-industry benchmarking and continual improvement. Customers just need to dial our toll free number and service will be available at the doorstep.

Download

Prime Rating at rated rpm ( as per ISO8528)1

kVA

5

7.5

10

kW

5

6

8

Genset Model



KG1-5AS

KG1-7.5AS

KG1-10AS1

Frequency

Hz

50

50

50

Power factor

lagging

0.8

0.8

0.8

Voltage

V

230(1∅)

230(1∅) & 415 (3∅)

Governing class (As per ISO 8528 Part-V)



G2

G2

G2

Noise level

dBA

< 75

< 75

< 75

Fuel Consumption*

At 100% Load

Ltrs/hr

1.6

2.3

3

At 75% Load

1.3

1.8

2.4

At 50% Load

1

1.4

1.8

Fuel tank capacity

Ltrs

70

50

50

Weight of genset with canopy (approx..)^

Dry

Kg

700

750

750

Wet

Kg

750

800

800

Overall dimensions of genset^

Length

mm

1600

1760

1760

Width

mm

820

820

820

Height

mm

1530

1330

1330

Electrical Battery starting voltage

Volts-DC

12

12

12

ENGINE

Engine Model



EA10 G1

EA16 G1

EA16 G1

Rated output (Prime Continuous rating as per ISO 8528-1)

kW

7.3

11.8

11.8

HP

10

16

16

No. of cylinder

Number

1

2

2

Cubic capacity 2

Ltrs

0.95

1.56

1.56

Bore x Stroke

mm

102 x 116

95 x 110

95 x 110

Rated Speed

RPM

1500

1500

1500

Aspiration

NA/TC/TA

TA

TA

TA

Lube Oil change period

hrs

500

500

500

Lube Oil Sump Capacity

Ltrs

3.5

6.5

6.5

Coolant Capacity

Ltrs

NA

NA

NA

ALTERNATOR

Insulation Class



Class H

Alternator Efficiency (at 100% load) 0.8 pf**

%

78

78.1

86

Alternator Efficiency (at   75% load) 0.8 pf**

Sec

= 20%

= 20%

= 20%

Max time to build up rated voltage at Rated RPM

< 5 sec provided engine reach the rated speed

KOEL's approach to meet revised CPCB norms

Revised CPCB norms are aimed at protecting the environment by reducing Genset emissions and improving emission quality. These are some of the most stringent emission norms in the world. To meet the new norms, KOEL R&D team had choice of multiple technologies. While selecting the technology, KOEL laid significant emphasis on long term needs of users viz:

  • High reliability and durability of Gensets: Owing to extreme operating conditions in India, preference has been given to robust configurations, that have been running successfully for several years
  • Low running costs: An effort to reduce emissions tends to increase the running costs. KOEL succeeded in achieving both in the same design.
  • Optimized fuel efficiency as per actual usage: KOEL Green Gensets are tuned to provide maximum fuel efficiency in the most common operating band. At KOEL, we call it O2E series (Optimal Operating Efficiency).
  • Affordable, On-site support: Proven technology ensures that product support is available close-by, without waiting for a specialist. KOEL team has taken special efforts to keep complex technologies at bay, which may require high on-site maintenance costs.

All this, while keeping the initial costs within the reach of a smart Genset buyer.

Watts of Savings

KOEL Chhota Chilli Gensets are powered by high-efficiency diesel engines. So you get the double benefit of higher efficiency and lower fuel costs. KOEL Chhota Chilli provides full rated power at just 1.5 Litre of Diesel per hour. That means a saving of upto 55% in your fuel costs, as compared to Petrol Gensets

Watts of Cooling

Don't limit your power back-up to 4 lights + 4 fans. Include the comforts of running Air-conditioner and Refrigerator . With KOEL Chhota Chilli, you can run your Air-conditioner and Refrigerator. So whether it's your family or clients, you can ensure their comfort during long hours of power cuts.

Watts on Wheels

Enjoy the benefits of mobility and portability in a Genset. KOEL Chhota Chilli rolls on wheels and is equipped with a trolley handle. Now you carry power with you for a beach party or a jungle camp. This feature is of great help for small establishments and mobile workshops too!

Watts on Wheels

The revolutionary sound absorption system makes you totally relaxed during power cut. It complies to the Noise Regulation and Emission Norms of Central Pollution Control Board. In compliance with the new emission norms, KOEL Chhota Chilli also keeps pollution at bay.

Watts of Assurance

KOEL Chhota Chilli Gensets reach you through a well-trained network of authorized dealers and are supported by over 5000 skilled engineers spread across India. Quality of service and response me is centrally monitored by KOEL. Dial the toll-free number and our authorized representative will be promptly available at your doorstep

Peace of mind Ownership

KOEL Chhota-Chilli Gensets have always been preferred for their robust design and reliability over long usage life.


KOEL Chhota-Chilli range carries the confidence of well-established and proven engine platforms. For compliance to revised CPCB norms, KOEL has carefully selected those technologies which not only retain, but enhance Gensets durability and on-site serviceability.


Thus, KOEL Gensets offer you many years of trouble-free performance; backed by the assurance of prompt support. Peace-of-mind driven by product reliability and low cost of ownership.
